DP-SDI Damping Coating

产品介绍: 1、Type of construction1)The construction of the damping coating and deck covering2)The PDP system (galvanized steel +damping coating + galvanized steel)2、Technical indexSerial NumberProject NameTechnical Index1ViscosityPart A≥90mPa.s,Part   B 10000-14000mPa.s2Density≤1300 kg/m33OrganicContent≤55%4Surface Drying Time≤5 h5Tensile Strength≥2.0 MPa6Elongation at Rupture≥70%7Adhesive Force≥1.8MPa8(邵A)Hardness60±59Loss Factor≥0.5 Under the normal temperature 20℃10Low Flame-SpreadAccord with IMO 2010 FTP Code Part 511Smoke and ToxicityAccord with IMO 2010 FTP Code Part 23、The performance characteristicsThis product has excellent damping noise reduction features;Easy to construction;After curing non-shrinkage;Products without solvent, green environmental protection;Coating with no seams, smooth appearance.4、Fire resistance ratingSurface flammability: comply with 1974 SOLAS IMO 2010 FTP Code Part 5.Flue gas and toxicity: comply with 1974 SOLAS IMO 2010 FTP Code Part 2.5、Recognised classification societyGL 、CCS 、EC6、Packaging and dosage (per square metre to calculate)Serial NumberMaterial NamePacking SpecificationDosage1DP-SDI Damping Coating20KG/Bucket0.01Bucket7、Construction technology7.1 The steel deck need remove rust, oil, dust and other sundry, and brush anti-rust primer;7.2 Mix stir well the part A and B of the damping coatings.7.3 Brush the damping coating DP - SDI evenly on the steel deck .8、Note8.1 After mixing,the damping coating must complete to lay within 30 minutes.8.2 This product should be stored in a cool, ventilated, dry, it is strictly prohibited to the rain, the sun,fire, away from heat source, storage temperature should be 15 ~ 40 ℃.
Features: This product has excellent damping noise reduction features;Easy to construction;After curing non-shrinkage;Products without solvent, green environmental protection;Coating with no seams, smooth appearance.
Fire rating: Surface flammability: comply with 1974 SOLAS IMO 2010 FTP Code Part 5.Flue gas and toxicity: comply with 1974 SOLAS IMO 2010 FTP Code Part 2.
Parameter GL 、CCS 、EC
颜色:
注意事项:
  • Details
  • Precautions
  • Features



1、Type of construction

  1)The construction of the damping coating and deck covering


  2)The PDP system (galvanized steel +damping coating + galvanized steel)


2、Technical index

Serial Number

Project Name

Technical Index

1

 Viscosity

Part A≥90mPa.s,Part   B 10000-14000mPa.s

2

Density

≤1300 kg/m3

3

  Organic Content



≤55%

4

Surface Drying Time

≤5 h

5

Tensile Strength

≥2.0 MPa

6

Elongation at Rupture

≥70%

7

Adhesive Force

≥1.8 MPa

8

(邵A)Hardness

60±5

9

Loss Factor

≥0.5 Under the normal temperature 20℃

10

Low Flame-Spread

Accord with IMO 2010 FTP Code Part 5

11

Smoke and Toxicity

Accord with IMO 2010 FTP Code Part 2









3、The performance characteristics

This product has excellent damping noise reduction features;Easy to construction;After curing non-shrinkage;Products without solvent, green environmental protection;Coating with no seams, smooth appearance.



4、Fire resistance rating

Surface flammability: comply with 1974 SOLAS IMO 2010 FTP Code Part 5.

Flue gas and toxicity: comply with 1974 SOLAS IMO 2010 FTP Code Part 2.



5、Recognised classification society

GL 、CCS 、EC



6、Packaging and dosage (per square metre to calculate)



Serial Number

Material Name

Packing Specification

Dosage

1

  DP-SDI Damping Coating

20KG/Bucket

 0.01Bucket



7、Construction technology

  7.1 The steel deck need remove rust, oil, dust and other sundry, and brush anti-rust primer;
  7.2 Mix stir well the part A and B of the damping coatings.

  7.3 Brush the damping coating DP - SDI evenly on the steel deck .



8、Note

  8.1 After mixing,the damping coating must complete to lay within 30 minutes.

  8.2 This product should be stored in a cool, ventilated, dry, it is strictly prohibited to the rain, the sun,fire, away from heat source, storage temperature should be 15 ~ 40 ℃.



This product has excellent damping noise reduction features;Easy to construction;After curing non-shrinkage;Products without solvent, green environmental protection;Coating with no seams, smooth appearance.
